3D Welded Wire Mesh Panel Bending Curved Outdoor Garden Fence
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 3D Wire Mesh Fence | Material | Low Carbon Steel |
|---|---|---|---|
| Place Of Origin | Hebei, China | Usage | Garden Fence |
| Service | Video Of Installation | Frame Finishing | PVC Coated |
| Color | Customized | Wire Diameter | 5.0mm.4.5mm,4.0mm,3.5mm |
| Mesh Size | 50*50mm,60*60mm,70*70mm,80*80mm | Panel Size | 2.0m,1.8m,1.5m,1.2m,etc |
| Opening | 50*200mm,50*100mm,etc | Post Shape | Peach Post. Square Post |
| Highlight | 3D Fence Welded Wire Mesh Panel,Curved Outdoor Garden Fence,3D Curved Garden Fence |
||
Product Description
3D Welded Wire Mesh Panel Bending Curved Outdoor Garden Fence
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | 3D wire mesh fence |
| Material | Low carbon steel |
| Place of Origin | Hebei, China |
| Usage | Garden fence |
| Service | Video of installation |
| Frame Finishing | PVC coated |
| Color | Customized |
| Wire Diameter | 5.0mm, 4.5mm, 4.0mm, 3.5mm |
| Mesh Size | 50×50mm, 60×60mm, 70×70mm, 80×80mm |
| Panel Size | 2.0m, 1.8m, 1.5m, 1.2m, etc |
| Opening | 50×200mm, 50×100mm, etc |
| Post Shape | Peach post, Square post |
Product Description
Our 3D curved wire mesh fence is constructed from high-quality low carbon steel galvanized wire, featuring multiple curves along the panel height for enhanced rigidity and strength. The panels can be filled with artificial hedge, plastic straps, rigid PVC slats, or sightscreen nets as needed. Each panel includes 30mm edges at the top for added durability.
Technical Specifications
- Material: High quality low carbon steel wire (Q235, Q195, S235J2)
- Process: Straightening → Cutting → Welding → Folding → Parkerising → Galvanizing → PVC coating → Packing
- Available Colors: Green (RAL6005), white (RAL9010), gray (RAL7004), yellow (RAL1021), black (RAL9005), blue (RAL5005), or custom colors
| Specification | Details |
|---|---|
| Wire diameter | 3-5mm (powder spraying); 3-5mm before coating, 4-6mm after coating (PVC coated) |
| Height × Width | Height: 0.63-2.4m; Width: 2m, 2.5m, 3.0m |
| Opening | 50×100mm, 50×150mm, 50×200mm, 75×150mm, etc. |
| PVC coated thickness | 1.0mm for above 3mm wire; 0.8-0.9mm for 3mm or thinner wire |
| Peach Post | 50×70×1.2mm, 70×100×1.2mm (post height matches panel height) |
| Surface treatment | Wire mesh panel: galvanized + PVC coated; Post: galvanized + powder spraying |
Key Features
- Direct connection with mesh eliminates need for buckles, enhancing security
- Attractive appearance with durable construction
- Simple structure for fast and convenient installation
- Effective anti-theft and anti-disassembly properties
Applications
- Industrial Facilities: Safety barriers around machinery, storage areas, and loading docks
- Commercial Buildings: Parking garages, staircases, and balconies
- Residential Properties: Balconies, terraces, and garden boundaries
- Public Spaces: Parks, pedestrian walkways, and bridges
- Transportation: Highways, railways, and airports
Fence Post Options
| Post Type | Dimensions | Thickness |
|---|---|---|
| Profile post | 48mm /60mm | 10/1.1/1.2mm |
| Square post | 40×40, 60×60mm | 1.5/2.0/2.5mm |
| Peach Post | 50×70, 70×100mm | 10/1.1/1.2mm |
| Rectangle Post | 40×60, 60×80mm | 1.5/2.0/2.5mm |
| I Post | 70×44, 100×66mm | 1.5/2.0/2.5mm |
Fence Panel Specifications
| Feature | Options |
|---|---|
| Width | 2.50m, 2.75m, 3.0m |
| Height | 830-2430mm in various increments |
| Mesh Size | 55×100mm, 50×150mm, 50×200mm, 55×200mm, 75×150mm, 60×200mm |
| Wire thickness | 4.0mm, 4.5mm, 5.0mm |
| Curves | 2-6 depending on panel height |
| Finish | Hot dip galvanized, galvanized + epoxy coated, galvanized + PVC coated |
| Number of brackets | 2-6 matching curve count |
Product Advantages
- Cost-effective fence posts with concrete pouring
- High strength with excellent overall stability
- Color plastic coating provides superior corrosion resistance and decorative effect
- Harmonious perimeter appearance with attractive outlook
After-Sales Service
- Assistance with freight cost optimization for both FOB and CIF terms
- Transparent production process with regular photo updates
- Support with shipment arrangement and customs clearance
- Comprehensive installation, maintenance, and repair instructions
Frequently Asked Questions
Can you provide a free sample?
Yes, we can provide samples for evaluation. Please contact our sales team for details (sample charges may apply).
What is your delivery time?
Typical production lead time is 15-25 days after receiving your 30% deposit.
Are you a manufacturer?
Yes, we have been manufacturing and exporting wire mesh products since 2013.
What payment terms do you accept?
We accept T/T or Irrevocable L/C at sight.
How can I get a quotation?
Please contact our sales team with your project requirements.
Product Connection Type
Product Accessories
Packing & Delivery
- Fence panel: Plastic film / wooden case + metal/wooden pallet
- Fence post: Plastic bag + metal/wooden pallet (with rainhat installed)
- Fence accessories: Plastic bag + carton box (clips & screws)
Accessories come in various types and materials to suit different installation needs. Our propulsion device makes installation easy and cost-effective.
