V Mesh Security Fence 60*60mm green Fence Garden Fence PVC 3 Curved Fence
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 3D Wire Mesh Fence | Material | Low Carbon Steel |
|---|---|---|---|
| Place Of Origin | Hebei, China | Usage | Garden Fence |
| Service | Video Of Installation | Frame Finishing | PVC Coated |
| Color | Customized | Wire Diameter | 5.0mm.4.5mm |
| Mesh Size | 50*50mm,60*60mm,70*70mm | Panel Size | 1.8m,1.5m |
| Opening | 50*200mm | Post Shape | Peach Post. Square Post |
| Highlight | Garden V Mesh Security Fence,PVC V Mesh Security Fence,60*60mm V Mesh Security Fence |
||
Product Description
V Mesh Security Fence 60×60mm Green Fence Garden Fence PVC 3 Curved Fence
Product Attributes
| Attribute | Value |
|---|---|
| Product Name | 3D wire mesh fence |
| Material | Low carbon steel |
| Place of Origin | Hebei, China |
| Usage | Garden fence |
| Service | Video of installation |
| Frame Finishing | PVC coated |
| Color | Customized |
| Wire Diameter | 5.0mm, 4.5mm |
| Mesh Size | 50×50mm, 60×60mm, 70×70mm |
| Panel Size | 1.8m, 1.5m |
| Opening | 50×200mm |
| Post Shape | Peach post, Square post |
3D V Bending Welded Mesh Fence Description
This anti-climb and anti-cut barrier is constructed with high-quality carbon steel wires, providing attractive, durable, and secure perimeter protection for industrial and commercial properties, public utilities, and electronic alarm systems. Ideal for military installations, airports, secure units, prisons, and locations requiring CCTV monitoring with no blind spots.
Specifications
- Material: High quality low carbon steel wire (Q235, Q195, S235J2)
- Process: Straightening and cutting → Welding → Folding → Parkerising → Galvanizing/Hot-dipped → PVC coating → Packing
- Colors: Green (RAL6005), white (RAL9010), gray (RAL7004), yellow (RAL1021), black (RAL9005), blue (RAL5005), or custom colors
| Specification | Details |
|---|---|
| Wire diameter | 3-5mm (powder spraying); 3-5mm before coating, 4-6mm after coating (PVC coated) |
| H × W (mm) | Height: 0.63-2.4m; Width: 2m, 2.5m, 3.0m |
| Opening (mm) | 50×100mm, 50×150mm, 50×200mm, 75×150mm |
| PVC coated thickness (mm) | 1.0mm for above 3mm wire; 0.8mm-0.9mm for 3mm or thinner wire |
| Peach Post | 50×70×1.2mm, 70×100×1.2mm (post height matches panel height) |
| Surface treatment | Wire mesh panel: galvanized + PVC coated; Post: galvanized + powder spraying |
Wire Mesh Panel Features
- Direct connection with mesh eliminates buckles for enhanced security
- Anti-theft and anti-disassembly design
- Attractive appearance with durable construction
- Simple structure for fast and convenient installation
Applications
Industrial construction fence
Airport & railway station service areas
Highway enclosure
Warehouse protection fence
School sports fields & stadiums
Garden & park security fence
Residential sites
Agriculture security fence
Animal enclosure fence
Fence Post Options
| Profile post | 48mm /60mm | 10/1.1/1.2mm thickness |
|---|---|
| Square post | 40×40, 60×60mm | 1.5/2.0/2.5mm thickness |
| Peach Post | 50×70, 70×100mm | 10/1.1/1.2mm thickness |
| Rectangle Post | 40×60, 60×80mm | 1.5/2.0/2.5mm thickness |
| I Post | 70×44, 100×66mm | 1.5/2.0/2.5mm thickness |
Fence Panel Specifications
| Width | 2.50m, 2.75m, 3.0m |
|---|---|
| Height | 830-2430mm in various increments |
| Mesh Size | 55×100mm, 50×150mm, 50×200mm, 55×200mm, 75×150mm, 60×200mm |
| Wire thickness | 4.0mm, 4.5mm, 5.0mm |
| Curves | 2, 3, 3, 4, 4, 4, 6 |
| Finish | Hot dip galvanized, galvanized and epoxy coated, galvanized and PVC coated |
| Nos. of brackets | 2, 3, 3, 4, 4, 4, 6 |
Wire Mesh Fence Advantages
- Concrete-poured fence posts for cost efficiency
- High strength with excellent overall stability
- Color plastic coating provides superior corrosion resistance and decorative effect
- Harmonious perimeter appearance with excellent visual appeal
After-Sales Service
- Competitive freight cost solutions for FOB or CIF terms
- Transparent third-party inspection process with production photos
- Assistance with shipment arrangement and customs clearance
- Comprehensive installation, maintenance, and repair instructions
Frequently Asked Questions
Can you express a free sample first?
Yes. Welcome to chat with our sales for more details. We always express the sample with charged.
What is your delivery time?
Approximately 15 to 25 days after receiving your 30% deposit.
Is that a real factory?
Yes. We have manufactured and exported wire mesh since 2013.
What is the payment terms?
Available by T/T or by Irrevocable L/C at sight.
How can I get the quotation?
Please contact us for detailed pricing information.
Product Connection Type
Product Accessories
Packing & Delivery
- Fence panel: Plastic film / wooden case + metal/wooden pallet
- Fence post: Plastic bag + metal/wooden pallet (with rainhat installed)
- Fence accessories: Plastic bag + carton box (clips & screws)
- Accessories available in various types and materials to meet specific requirements
- Propulsion device enables easy gripping and fast installation, reducing costs
