1.5m Height 3D Wire Mesh Fence with 50x200mm Opening Made from Low Carbon Steel
Product Details
| Product Name | 3D Wire Mesh Fence | Material | Low Carbon Steel |
|---|---|---|---|
| Place Of Origin | Hebei, China | Usage | Garden Fence |
| Service | Video Of Installation | Frame Finishing | PVC Coated |
| Color | Customized | Wire Diameter | 5.0mm |
| Mesh Size | 50*50mm,60*60mm | Panel Size | 1.5m |
| Opening | 50*200mm | Post Shape | Peach Post. Square Post |
| Highlight | 3d Curved Wire Mesh Fence,3d Curved Welded Mesh Fence,PVC Coated curved wire fence |
||
Product Description
3D Curved Welded Mesh Fence 1.5m PVC Coated 3D Curved Wire Mesh Fence
Product Overview
Security Fence is well known worldwide as an anti-climb and anti-cut barrier, providing high-quality carbon steel wire protection. Designed for attractive, long-lasting, and secure perimeter protection for industrial and commercial properties, public utilities, and perfectly suited for electronic alarm and detection systems with no blind spots for CCTV. Ideal for airports, secure units, and prisons.
3D curved Welded Wire Mesh Fencing provides essential safety and security protection against various threats. This affordable and durable fencing solution is widely used for residential walls and offers easy installation on fences.
Specifications
- Material: High quality low carbon steel wire (Q235, Q195, S235J2)
- Process: Material → Straighten and cutting → Welded → Making folds → Parkerising → Galvanized/Hot-dipped → PVC coated → Packing
- Colors: Green (RAL6005), White (RAL9010), Grey (RAL7004), Yellow (RAL1021), Black (RAL9005), Blue (RAL5005), and custom colors available
| Specification | Details |
|---|---|
| Wire diameter | 3-5mm (powder spraying); 3-5mm before coating, 4-6mm after coating (PVC coated) |
| H x W (mm) | Height: 0.63-2.4m, Width: 2m, 2.5m, 3.0m |
| Opening (mm) | 50x100mm, 50x150mm, 50x200mm, 75x150mm, etc. |
| PVC coated thickness (mm) | 1.0mm for above 3mm wire; 0.8mm-0.9mm for 3mm or thinner wire |
| Peach Post | 50x70x1.2mm, 70x100x1.2mm, post height matches panel height |
| Surface treatment | Wire mesh panel: galvanized + PVC coated, galvanized + powder spraying. Post: galvanized + powder spraying |
Features
3D wire mesh fence connects directly with the mesh without additional buckles, providing effective anti-theft and anti-disassembly protection. Features include beautiful appearance, durability, simple structure, and fast, convenient installation.
Applications
- Industrial construction fence
- Airport, railway station service area
- Highway enclosure
- Warehouse protection fence
- School sports field, stadium
- Garden, park security fence
- Residential site
- Agriculture security fence
- Animal enclosure fence
Fence Post Options
| Post Type | Dimensions | Thickness |
|---|---|---|
| Profile post | 48mm / 60mm | 10/1.1/1.2mm |
| Square post | 40x40, 60x60mm | 1.5/2.0/2.5mm |
| Peach Post | 50x70, 70x100mm | 10/1.1/1.2mm |
| Rectangle Post | 40x60, 60x80mm | 1.5/2.0/2.5mm |
| I Post | 70x44, 100x66mm | 1.5/2.0/2.5mm |
Fence Panel Specifications
| Parameter | Specifications |
|---|---|
| Width | 2.50m, 2.75m, 3.0m |
| Height | 830, 1030, 1230, 1430, 1630, 1830, 2030, 2230, 2430mm |
| Mesh Size | 55x100mm, 50x150mm, 50x200mm, 55x200mm, 75x150mm, 60x200mm |
| Wire thickness | 4.0mm, 4.5mm, 5.0mm |
| Curves | 2, 3, 3, 4, 4, 4, 6 |
| Finish | Hot dip galvanized, galvanized and epoxy coated, galvanized and PVC coated |
| Nos. of brackets | 2, 3, 3, 4, 4, 4, 6 |
Advantages
- Fence posts made with concrete pouring, low cost
- High strength, good overall stability
- Color plastic coating/spraying layer provides excellent anti-corrosion and decorative effects
- Harmonious perimeter appearance with good outlook
After-Sales Service
- Assistance with finding lowest freight costs for FOB or CIF pricing
- Full cooperation with third-party inspections and production photo updates
- Support with shipment arrangement and customs clearance
- Comprehensive installation, maintenance, and repair instructions
Frequently Asked Questions
Q: Can you provide a free sample?
A: Yes. Contact our sales team for details. Samples are available with charge.
Q: What is your delivery time?
A: Approximately 15-25 days after receiving 30% deposit.
Q: Are you a real factory?
A: Yes. We have manufactured and exported wire mesh since 2013.
Q: What are the payment terms?
A: Available by T/T or Irrevocable L/C at sight.
Q: How can I get a quotation?
A: Please contact us directly.
Product Connection Type
Product Accessories
Packing & Delivery
- Fence panel: Plastic film / wooden case + metal/wooden pallet
- Fence post: Plastic bag + metal/wooden pallet (with rainhat installed)
- Fence accessories: Plastic bag + carton box (clips & screws)
Accessories available in different types and materials as needed. No special attachment required for piping installation - uses propulsion device for easy gripping, fast installation, and cost reduction.
