5ft Power Coated Welded Wire Security Fence 3D Curved Security Garden Fence
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 3D Wire Mesh Fence | Material | Metal Steel |
|---|---|---|---|
| Place Of Origin | Hebei, China | Usage | Security Fence |
| Service | Video Of Installation | Frame Finishing | Galvanized |
| Color | Customized | Package | Pallet |
| Post Shape | Square Post | Feature | Waterproof |
| Certificate | ISO9001 | Panel Size | 1830x3000mm |
| Highlight | 5ft Welded Wire Security Fence,Power Coated Welded Wire Security Fence,3D Curved Security Garden Fence |
||
You can tick the products you need and communicate with us in the message board.
Product Description
5ft Power Coated Welded Wire Security Fence 3D Curved Security Garden Fence
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | 3D wire mesh fence |
| Material | Metal steel |
| Place of Origin | Hebei, China |
| Usage | Security fence |
| Service | Video of installation |
| Frame Finishing | Galvanized |
| Color | Customized |
| Package | Pallet |
| Post Shape | Square post |
| Feature | Waterproof |
| Certificate | ISO9001 |
| Panel Size | 1830x3000mm |
Product Description
The 3D Curved Welded Wire Mesh is an economical yet robust fence system featuring longitudinal folds that enhance its strength. Constructed from high-quality low carbon steel wire, these fence panels undergo surface treatments including hot-dipped galvanization or electric polyester powder spray coating.
Key Features
High strength construction
Excellent steel nature capacity
Attractive modern appearance
Wide field of vision
Easy installation
Comfortable and bright finish
Waterproof and weather-resistant
Rodent and rot proof
Technical Specifications
| Material | High quality low carbon steel wire (Q235, Q195, S235J2) |
|---|---|
| Process | Material → Straighten and cutting → Welded → Making folds → Parkerising → Galvanized/hot-dipped → PVC coated → Packing |
| Available Colors | Green (RAL6005), White (RAL9010), Gray (RAL7004), Yellow (RAL1021), Black (RAL9005), Blue (RAL5005), or customized |
| Surface Treatment | Powder coated, PVC coated, hot-dipped galvanized |
Standard Panel Specifications
| Panel Height | Panel Length | Wire Diameter | Mesh Size | Folds |
|---|---|---|---|---|
| 1.03m | 2.5m | 4.8mm | 200x50mm | 2 |
| 1.23m | 2.5m | 4.8mm | 200x50mm | 2 |
| 1.53m | 2.5m | 4.8mm | 200x50mm | 3 |
| 1.73m | 2.5m | 4.8mm | 200x50mm | 3 |
| 2.03m | 2.5m | 4.8mm | 200x50mm | 4 |
Applications
This 3D V Mesh Security Fence is ideal for various security applications including:
- Municipal green fields and flowerbeds
- Workplace and road security
- Airport and harbor perimeter protection
- Construction sites and residential buildings
- Sports fields and warehouses
- Highway and railway station security
Installation Components
Fence Post: Each post comes with a protective cap and plastic film, packed on metal pallets.
Accessories: Complete set of clips and screws, packed in plastic film and carton boxes.
Packing & Delivery
- Fence panel: Plastic film/wooden case + metal/wooden pallet
- Fence post: Plastic bag + metal/wooden pallet (with rainhat installed)
- Fence accessories: Plastic bag + carton box (clips & screws)
Our Services
- Free samples available
- Free technical drawings provided
- OEM and ODM orders accepted
- Competitive factory pricing with quick response
- Extensive exporting experience
- Quality guarantee with full compensation policy
Frequently Asked Questions
Can you provide a free sample first?
Yes, we can provide samples. Please contact our sales team for details (sample shipping costs may apply).
What is your delivery time?
Typically 15-25 days after receiving your 30% deposit.
Are you a real factory?
Yes, we have been manufacturing and exporting wire mesh products since 2013.
What are your payment terms?
We accept T/T or Irrevocable L/C at sight.
How can I get a quotation?
Please contact us through the provided contact information.
